Used for high-speed transmission network applications in buildings (indoor optical cables) or between buildings (outdoor optical cables): Optical cable backbone cabling; Horizontal cabling (fiber optic) to the desktop using indoor tight-buffered structure 6 optical cables.
All adopt low-smoke and halogen-free (LSZH) outer sheath, environmentally friendly, safe and reliable in performance.
Complies with IEC61034 and EN60793-2-10 specifications: Type 2002A1b.
Suitable for tight-buffered structure optical cables: 900μm easy-to-strip fiber buffer layer, or loose-tube structure optical cables: 250μm easy-to-strip fiber buffer layer.
Light green LSZH optical cable outer sheath, no metal components.
Optical Performance Indicator Requirements for Fiber Optic Connectors
a) The insertion loss (including repeatability) of any plug connected to a standard plug via a standard adapter shall be ≤ 0.2dB.
b) The insertion loss of two plugs connected via a standard adapter shall be ≤ 0.3dB.
c) After various tests, the allowable variation of insertion loss shall be ≤ 0.2dB, and the variation of return loss shall be ＜ 5dB.
